Hydroexcavators Wet/Dry

GapVax delivers optimum weight distribution for "Bridge Law" compliant states. The 15, 000 lb . payload and low-profile (12 • 2 " ) ovent/1 weight make it the ideal solution for all-around hydro excavation projects. The GapVax superior vacuum system with wet/dry filtration is quiet, reliable, and simple.

This superior filtration design includes ultra-efficient centrifugal cyclone separators and long-lasting filter bags. The VHX offers a powerful combination of a 13 GPM. 3.000 PSI water system with optional 200 CFM air compressor system. The GapVax standard full tilting debris body allows for fast unloading and easy cleanout. Ease of operation and maintenance keep the operator in mind as with all of our products. Outperform the competition and stay road legal width the best truck in die business! The OapVax VHX is ready for anything!

Specifications

  • 8"telescoping boom 22' reach with a 15° downward pivot
  • Optimized for hydro excavation
  • Positive displacement pump; 4,000 CFM, 28" Hg
  • 600HP transfer case with air-shift engagement
  • Specifically desgined ultra-quiet air injection and discharge silencers
  • Wet or Dry singe mode filtration, Top loading debris tank, 14" stainless steel floatball shutoff, two centrifugal cyclone material separators
  • Baghouse with 21 snap-ring type fileter bags and heavy-duty galvanized cages
  • 7.5 Cubic yards
  • Dump angle at over 45° for fas unloading and easy clean-out
  • Full opening tailgate with field-adjustable locks that assure a completed seal
  • 750 gallons of water (two 375 gallon poly tanks)
  • Hydraulically-driven tri-plex water pump
  • 13 GPM/3.000 PSI (other options available)
  • Height conscious at 12'2"

Standard Equipment

  • Noise and vibration dampening mounts on blower and transfer case
  • High efficiency, low maintencance aluminum air duct construction with cleanout access
  • Full bearing body pivot
  • heavy-duty electric vibrator with thermal overload protection
  • Dual rear splash plates
  • Body and tailgate safety props
  • Stainless steel debris body
  • Full-sized vertical heated cabinet
  • Onboard scale
  • Water heater options 400,000 BTU or 575,000 BTU
  • Glycol injection
  • 200 CFM Air compressor system
  • Liquid level load indicator
  • Auxiliary lift axles
  • Tailgat load port
  • Various tube racks, toolboxed, and storage
  • Various lighting options
  • Remote wireless controls
